Warn 97740 16.5TI-S Electric Winch - 16,500 lbs. Pull Rating, 80 ft. Synthetic Line

by Warn
SKU wrn97740

Save $528.00 Save $528.00
Original price $3,519.99
Original price $3,519.99 - Original price $3,519.99
Original price $3,519.99
Current price $2,991.99
$2,991.99 - $2,991.99
Current price $2,991.99

Limited Time Offer

Use Code "Recon" at Checkout for Special Pricing

1-Year Low Price Guarantee

We offer a 1-Year Low Price Guarantee on everything we sell. If you see an item you purchased cheaper within 1 year of your purchase email sales@reconrecovery.com and we’ll refund the difference. Read More

With a massive 16,500 lbs. of pulling capacity, the 16.5ti-s is not only the most powerful truck winch we make, it's also now available with 80' of 3/8" lightweight, easy-to-handle Spydura® Pro synthetic rope. The rope's heat-treated construction provides maximum tensile strength, and the temperature-resistant sleeve on the first layer provides maximum heat protection. This winch also features a thermometric indicator which provides operator feedback during the winching process and is great for the biggest, heaviest vehicles on or off the pavement.

Overview

16,500 lb. capacity

Includes 80' of 3/8" Spydura Pro synthetic rope

Includes 18,000 lb capacity EPIC hook

Thermometric indicator LED provides operator feedback

Large-frame winch architecture mounts feet forward

Contactor control for the ultimate in reliable electronics

Powerful, efficient series-wound motor

Durable, smooth three-stage planetary gear train

Best-in-class cone brake

Limited Lifetime Warranty for Mechanical Components. Limited Seven (7) year warranty for Electrical Components.

Specifications
  • Line Material: Synthetic
  • Maximum Pull Rating: 16500 Pounds
  • Remote Type: Wired
  • Brake: Direct Drive Cone
  • Color: Gray
  • Drive Gear Type: Planetary
  • Electrical Control Type: Contactor
  • Fairlead Type: Hawse
  • Freespooling: Yes
  • Gear Reduction Ratio: 315:1
  • Includes Mounting Hardware:
  • Line Diameter: 3/8 Inch
  • Line Length: 80 Feet
  • Max Amp Draw / Line Pull:
  • Max Load Line Speed:
  • Meets SAE J706 Standard: No
  • Motor Horsepower:
  • Motor Type: Series Wound
  • Mounting Hole:
  • Mounting Pattern Length:
  • Mounting Pattern Width:
  • Quantity: Sold individually
  • Recommended Use: Trucks and SUV
  • Thermal Shutoff:
  • Type: Electric
  • Voltage: 12 Volts
Warranty
  • Warranty: Limited Lifetime Manufacturer's Warranty For Mechanical Components
VR EVO SERIES WINCH

VR EVO SERIES WINCH

Don’t let the price fool you; this isn’t a light-duty winch. With the lowest amp draw and fastest line speed under load, the WARN VR EVO winches are the hardest-working standard-duty winches we’ve ever offered. The VR EVO winch lineup features IP68-rated waterproof construction, a two-in-one wireless/corded remote, and our legendary reliability. Plus, they’re covered by our industry leading limited lifetime warranty.

SHOP EVO SERIES
ZENON SERIES WINCH

ZENON SERIES WINCH

The WARN ZEON winches continue to redefine winching. ZEON is the premium winch line for trucks, Jeeps, and SUVs, and provides unmatched durability, performance, and style. These winches have become top sellers for a good reason: They’ve been the top choice of editors and off-roaders worldwide, and look as good as they perform.

Shop ZENON SERIES
WARN UTV & ATV SERIES WINCHES

WARN UTV & ATV SERIES WINCHES

Add some brainpower to your horsepower. With advanced Motactor (motor/contactor) digital technology, IP68 rated, and a compact, easy-to-install design, the WARN ATV/UTV winches are the best on the market. With pulling capacities from 3,500 to 5,500 lbs, these state-of-the-art winches will help you go prepared for any situation.

SHOP UTV & ATV WINCHES
ZEON PLATINUM SERIES WINCHES

ZEON PLATINUM SERIES WINCHES

With state-of-the-art features, cutting-edge technology, and world-class engineering, the WARN ZEON Platinum is the future of winching. The one-of-a-kind Advanced Wireless Remote controls the clutch, power in/power out, plus it displays motor temperature and vehicle battery info. It also can control two 12-volt accessories, which can be plugged directly into the winch.

SHOP ZENON PLATIUM SERIES

With a massive 16,500 lbs. of pulling capacity, the 16.5ti-s is not only the most powerful truck winch we make, it's also now available with 80' of 3/8" lightweight, easy-to-handle Spydura® Pro synthetic rope. The rope's heat-treated construction provides maximum tensile strength, and the temperature-resistant sleeve on the first layer provides maximum heat protection. This winch also features a thermometric indicator which provides operator feedback during the winching process and is great for the biggest, heaviest vehicles on or off the pavement.

16,500 lb. capacity

Includes 80' of 3/8" Spydura Pro synthetic rope

Includes 18,000 lb capacity EPIC hook

Thermometric indicator LED provides operator feedback

Large-frame winch architecture mounts feet forward

Contactor control for the ultimate in reliable electronics

Powerful, efficient series-wound motor

Durable, smooth three-stage planetary gear train

Best-in-class cone brake

Limited Lifetime Warranty for Mechanical Components. Limited Seven (7) year warranty for Electrical Components.

  • Line Material: Synthetic
  • Maximum Pull Rating: 16500 Pounds
  • Remote Type: Wired
  • Brake: Direct Drive Cone
  • Color: Gray
  • Drive Gear Type: Planetary
  • Electrical Control Type: Contactor
  • Fairlead Type: Hawse
  • Freespooling: Yes
  • Gear Reduction Ratio: 315:1
  • Includes Mounting Hardware:
  • Line Diameter: 3/8 Inch
  • Line Length: 80 Feet
  • Max Amp Draw / Line Pull:
  • Max Load Line Speed:
  • Meets SAE J706 Standard: No
  • Motor Horsepower:
  • Motor Type: Series Wound
  • Mounting Hole:
  • Mounting Pattern Length:
  • Mounting Pattern Width:
  • Quantity: Sold individually
  • Recommended Use: Trucks and SUV
  • Thermal Shutoff:
  • Type: Electric
  • Voltage: 12 Volts
  • Warranty: Limited Lifetime Manufacturer's Warranty For Mechanical Components

Customer Reviews

Based on 6 reviews
100%
(6)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
S
Stacy
I like it

Amazing piece of equipment

A
Alexzander Rivera
5 star

Wow, what a beast! Fit and finish are impeccable. Direction for install are the typical graphical nonsense which I find very confusing, but I got it done none the less . Use it on a one ton truck with camper. Warn epic hook a nice touch.

M
Mathias Jackson
Quality Product

This wench is a beast and pulled my jeep and a full size tractor when i was using it to try to pull down a tree. love the wireless to.

K
Korbin Harper
Really like it

Strong and easy to use

C
Callum Monroe
very durable

Warns are pricey but this is my second one in 30 years. I got the xenon platinum for its water proof. I tend to go in a lot of water. Warns are very reliable and probably the best winches ever.
