ReadyLIFT Suspension offers a suspension product line designed for the 2011-2016 Ford Super Duty (with dually rear spring pack) equipped with diesel engines. The 2011-2016 F250 4WD 3.5" F/3.0" R SST Lift Kit provides precise front and rear lift, accommodating wheel and tire combinations up to 35" while preserving the smooth OEM ride and drivability. The kit includes 3.5" powder-coated steel coil spring spacers, sound isolators, shock extensions, sway bar frame mount spacers, bump stop extensions, carrier bearing spacer, track bar relocation bracket, radius arm drop brackets, and OEM-style 5.0" Rear Lift Blocks with longer u-bolts for the dually rear spring pack. This system enhances the vehicle's appearance while retaining factory ride quality.

It's tailored for the 2011-2016 Ford F250 4WD with dually rear springs and maintains OEM ride and sound quality with 3.5" coil spacers and sound isolators. Shock extensions enable the use of existing front shocks. Radius arm drop brackets and a track bar relocation bracket maintain suspension geometry. Sway bar mount spacers are included to level the truck.

Bump stop extensions preserve the factory distance between the bump stop and axle, and a carrier bearing spacer allows driveshaft angle adjustment. The use of cast iron 5.0" rear lift blocks (3.0" lift) creates a lifted stance with a 0.75" rake. ReadyLIFT's 3.5" SST Lift Kit is an easy, safe way to lift your Super Duty without compromising the factory ride. It features Smart Suspension Technology, ensuring a hassle-free installation with no cutting or drilling required.

The kit is backed by a lifetime warranty against manufacturing defects.

Please note that it is not compatible with the 2011-2016 Super Duty with the 6.2-liter gas engine, and aftermarket or factory add-on air spring/load leveling kits that attach to the bump stop tangs are not supported, as they can void block warranties and cause block bump stop tang failure.

Features

• Max Lift: 3.5
• Front lift: 3.0
• Rear lift: 3.0
• Maximum tire diameter: 35
• Designed for trucks with Dually Rear Springs ONLY
• Compatible with 201116 F-350 4WD Dually models
• Specifically designed for use with trucks with twopiece drive shafts

Refer to the tire fitment guide along with the year make model data. Tire fitments shown are for Maximum size and based on a no rub or no modifications required fitment. ReadyLIFT & Recon Recovery is not responsible if the listed max sizes are exceeded. Due to differences in manufacturing, dimension and inflated measurements, tire and wheel combinations should be test fit prior to installation.

Fitment

• 2011-2016 Ford F-250 Super Duty (Standard Box) — 4WD
  • Lift: 3.5" F-3.0" R | Max Tire: 37" x 12.5" | Wheel Width: 9" | Backspacing: 5" | Offset: 0
• 2011-2016 Ford F-350 Super Duty (Standard Box) — 4WD
  • Lift: 3.5" F-3.0" R | Max Tire: 37" x 12.5" | Wheel Width: 9" | Backspacing: 5" | Offset: 0
• 2011-2016 Ford F-450 Super Duty (Standard Box) — 4WD

Specifications

• Fitment: Direct Fitment
• Front or Rear: Front and Rear
• Front Lift Height: 3.5 Inches
• Front Lift Component: Coil Spring Spacer
• Rear Lift Height: 3 Inches
• Rear Lift Component: Block and U-bolt
• Max Tire Size: 37 Inch
• Installation Time: 5+ Hours
• Install Difficulty: Difficult Requires Professional Installation
• Country of Origin: TN

Notes

• (1) NOTE: Alignment cams are suggested for all kits

Warranty

READYLIFT® “NO HASSLE” PRODUCT WARRANTY

This unique “no hassle” product warranty proves their commitment to the quality of every product that ReadyLIFT produces. ReadyLIFT product warranty only extends to the Original Purchaser of any ReadyLIFT product. If it breaks, they'll give you a new part.

Any ReadyLIFT products containing missing or defective components will be covered under warranty by ReadyLIFT. Please contact Recon Recovery to initiate a warranty claim. In the event of a defective product, ReadyLIFT may request a return of the defective product (at ReadyLIFT expense) so the quality team can analyze the nature of the defect. Returning defective product will not delay the replacement part delivery.

ReadyLIFT leveling kit, block kits and lift kit products are NOT intended for off-road abuse. Any abuse or damage as a result of off-road use voids the warranty of the ReadyLIFT product. Exception: ReadyLIFT Jeep SST and Terrain Flex Lift Kits are designed for normal off-road use to complement the Jeep vehicle's off-road capability. All Jeep Lift Kit products are covered under warranty when used in recreational off-road environments.

Wearable components including, but not limited to, shocks, ball joints, heim joints, bushings, and steering extensions, are covered for up to 1-year. Labor, installation, surcharges or any other applicable fees from the original purchase are non-refundable. ReadyLIFT is not responsible for any consequential damage to vehicles.

WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer, and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov/product.
